TEAC
TEAC NT-507T Network Transport
TEAC NT-507T Network Transport
RRP: $2499.99
Network Streaming Transport
NT-507T
A High-Quality Network Solution for Your DAC to Maximize Music Streaming Enjoyment
With TEAC's unwavering commitment to exceptional sound quality and intuitive operability, the NT-507T takes music streaming enjoyment to a new level. As a network streaming transport in the Reference 500 Series designed exclusively for USB digital output, it pairs seamlessly with your existing DAC, such as the UD-507, featuring TEAC’s proprietary discrete “TRDD 5” DAC to deliver reference-grade sound from online streaming and locally stored NAS audio sources.
Driven by the advanced TEAC Network Engine G4, the NT-507T is engineered from the ground up with sound quality as its highest priority. A large linear power supply replaces noise-inducing switching circuits, ensuring dynamic, natural, and fluid sound reminiscent of vinyl playback. Network connectivity is equally versatile, offering Ethernet RJ45 and SFP Optical inputs, and Wi-Fi 6 support. It's high-fidelity USB output, equipped with an independent power supply section guarantees pristine signal transmission to your DAC.
User experience has been carefully refined for today's streaming lifestyle. The NT-507T integrates smoothly with OpenHome-compatible apps such as the TEAC HR Streamer, and it's USB Volume Function lets you control the volume of connected USB DACs or preamps directly from the app. It supports leading high-resolution streaming services including Qobuz, Spotify, TIDAL, and Tune-In, and features a dedicated Roon Ready mode for the most demanding audiophiles. Two USB ports also allow direct connection of flash drives, HDDs, or SSDs, enabling the NT-507T to serve as a simple music server (NAS).
Key Features
Pure Network Streaming Transport: Purpose-built for high-purity digital streaming playback without a DAC.
Extremely Versatile: Seamlessly integrates with the UD-507 and other USB DACs.
Next-Generation "TEAC Network Engine G4": Specialized for ultimate quality streaming experience.
Large Linear Power Supply: Delivers dynamic, smooth and natural playback with exceptional control.
Dual Network Interface with Integrated Network Switch (SFP + RJ45 Port)
SFP Optical Network Connectivity: Provides Isolation from Network Noise.
Wi-Fi 6 Wireless Network Connectivity: High-quality performance, switchable between wired LAN connection.
High Quality USB Type-A Output: Supports DSD 22.5 MHz and PCM 768 kHz / 32-bit format.
Clean and Powerful Toroidal Core Transformer: Four Independent windings supply dedicated power for network, USB outputs, Wi-Fi, and LED sections.
Low-Feedback, Discrete DC Power Regulator: Provides excellent dynamics and imaging
TEAC HR Streamer App: Provides extremely comfortable operation on smartphone/tablet.
OpenHome Compliant: The system can be controlled with other OpenHome apps.
Comprehensive Streaming Service Support: Tidal, Tidal Connect, Qobuz, Qobuz Connect, Spotify, Tune-In
Roon Ready / Roon-Only High-Quality Mode: Dedicated playback mode for audiophile-grade Roon integration.
USB Volume Control Function: Enables volume control on USB DAC/Preamp via app, through NT-507.
Music Server Function: Two USB ports allow playback from flash drives, HDDs, or SSDs.
Extensive File Format Support: Wide compatibility with modern high-resolution audio formats.
Semi-Floating 2.8 mm Aluminum Top Panel: Suppresses vibration and enhances tonal clarity.
Stress-Less Isolation Feet: Provide clear focus, natural timbre, and refined musical texture.
Two Color Options: Silver/Black
Specifications
Network section
●Supported file formats: FLAC, ALAC, WAV, AIFF, MQA, DSF, DSDIFF (DFF), DoP, MP3, AAC (m4a container)
●Ethernet port x1
●SFP Port x1
●Wireless LAN specifications: 802.11a/b/g/n/ac/ax (2.4GHz, 5GHz)
●USB drive ports: Type-A x1 (Rear), Type-C x1 (Front) *Maximum power rating of bus-powered devices: 500mA
●Supported sampling frequencies: PCM 44.1 to 768 kHz, 16/24/32 bit (integer / floating format),
DSD 2.8 MHz, 5.6 MHz, 11.2 MHz, 22.5 MHz
Digital Outputs
●USB Type-A x1
General
●External dimensions (W x H x D, approx.): 290 × 84.7 × 246 mm (11 1/2" × 3 3/8" × 9 3/4")
●Weight: approx. 4.3kg (9.5 lbs)
