Advance Paris A10 APEX Integrated Amplifier

RRP - $3499

The APEX range is the result of the Advance Paris engineering team’s efforts to push the boundaries of our Classic range in terms of performance and functionality.

The A10 APEX features the hybrid design of our flagship integrated amplifiers, with high power output (130W in Class A/B at 8 Ω) and the same musicality that is recognized worldwide.

To celebrate the brand’s 30th anniversary, we are presenting a special limited edition 30TH EDITION with a black finish and white VU meters.

The A10 APEX combines timeless design with modern technology to deliver power, musicality and ease of use.

Connections & sources

• 7 analogue inputs: (5x) RCA, (1x) MM phono, (1x) XLR
• 5 digital inputs: 3 optical, 1 coaxial, 1 USB for computer
• Bluetooth aptX AD - LL option (A-BTC module)
• 1 HDMI eARC socket with A10 APEX start-up when the TV is switched on and volume control is engaged.


Functions & settings

• Settings: loudness, bass, treble, balance
• Automatic standby adjustable from 5 to 60 minutes
• Trigger OUT to synchronize the switching on/off of a separate power amplifier
• Trigger IN to power the A10 APEX on with the use of a compatible preamp/processor (typically using AMP-IN input) separate power amplifier
• Connection possible for 2 subwoofers + separate PREOUT output and AMP-IN input
• Fixed REC-OUT output for recorder (cassette, MD, etc.)

Advanced options

• High-Bias switch: activates double Class A bias to enjoy Class A at higher power levels

Key features

• Preamplifier with 2 ECC81/12AT7 tubes offering warm sound and great musicality.
• 2x130W Class A/B amplifier combining power and listening refinement.
• High-Bias function activating double Class A bias to enjoy Class  A at higher power.
• Bluetooth aptX AD - LL option (optional A-BTC module): allows you to send music from your smartphone/tablet/computer to the A10 APEX or send sound from a source connected to the A10 APEX to Bluetooth headphones.
• Zone A and B: Dual speaker outputs

TECHNICAL SPECIFICATIONS

• Output power 8Ω 130W (THD+N 1%, 1kHz, 2 channels driven)
• Output power 8Ω (20Hz - 20kHz, THD+N inf. to 0.07% 120W (2 channels driven)
• Output power 4 Ω 198W (THD+N 1%, 1kHz, 2 channels driven)
• Output power 4Ω (20Hz - 20kHz, THD+N inf. to 0.07% 183W (2 channels driven)
• Frequency response (+/-1dB) 20Hz > 80kHz (31W, 8Ω)
• Distortion 0.045% (1kHz, 90W, 8Ω)
• Signal-to-noise ratio 106dB (1kHz, 90W, 8Ω)
• AC input compatibility 115/230V 50/60Hz
• Transformer type/power Toroidal / 380VA
• DAC ESS9018
• Digital inputs (3x) Optical: 24-bit - 192kHz PCM
  • (1x) Coaxial: 24-bit - 192kHz PCM
  • (1x) USB audio 24-bit/192kHz PCM - DSD64 - DSD128
  • HDMI eARC: PCM Stereo
  • A-BTC input  For A-BTC Bluetooth receiver (optional)
• Analogue inputs RCA LINE level (5x)
  • MM PHONO level (1x) with ground
  • XLR Line level (1x)
• Analogue outputs RCA: REC-OUT (x1), PRE-OUT (x1), SUB-OUT (x2)
• Headphone jack 6.35mm jack
• High Bias Yes, ON/OFF switch
• Update Via USB key on ‘UPDATE’ port
• Speaker terminals (2x) Screw terminals compatible with bare cable, spade and banana plugs
• Remote control Infrared, REM-19, compatible with A8 APEX, A10 APEX, A12 APEX,  and ACD APEX
• Trigger jack (2x) Input and Output, 12V
• Product dimensions (WxHxD in cm) 43x17.5x35.1
• Packaging dimensions (WxHxD in cm) 54.6x30.3x49.4
• Gross weight (kg) / Net weight (kg) 16.3 / 12.9
• Model no. A10 APEX 30TH EDITION
• EAN code 3 760 179 292 763
