Integra Integrated
Encapsulating the essence of our Integrated Amplifier range, Integra plunders its bigger stablemate for its internal building blocks.
Offering an impressive sound quality that's obvious from the first few moments, suddenly you escape into a soundstage you didn't expect to find in your music collection.
"INTEGRA played any music I fed it with near perfection"
- Janine Elliot
Key Features
- Remote Volume Control
- Pellar Integated Phono
- Headphone Amplifier
Super Powers
Powering your music is a huge transformer, electrical reservoir and the mono amplifiers from our SIGSUM. Avoiding unwanted circuitry noise which tarnishes the sound, we have harnessed a silky-smooth ALPS volume control and bespoke capacitors from our Reference models offering a warmth that makes listening an endless pleasure.
“If you want to get blown away – this is an amplifier worth hearing”
- Noel Keywood
Winning Design
From inception a multitude of Industry accolades have been bestowed on this musical amplifier, connecting you vividly to the performance, either through the built in Pellar phono stage or its numerous line inputs. Listening with loudspeakers opens up a glorious soundstage and for those moments of solitude you have the exceptional headphone output. A winning design that is also winning hearts and awards.
"Notes start and stop precisely, expressing rhythmic flow"
- John Pickford
Related Products
Specifications |
|
| POWER OUTPUT: | 90W 8Ω |
| HARMONIC DISTORTION: | 0.003% (80% POWER 8Ω 1KHz) |
| LOUDSPEAKER IMPEDANCE: | 4-16Ω |
| PHONO INPUTS: | 1x RCA 1x LOADING |
| GAIN: | 48dB – 60dB – 70dB |
| INPUT RESISTANCE: | 47K - CUSTOM (500Ω LOADING PLUGS SUPPLIED) |
| INPUT CAPACITANCE: | 100pF |
| LINE INPUTS: | 4x RCA LINE INPUTS |
| OUTPUTS: | 4x GOLD PLATED HIGH CURRENT |
| LINE LEVEL OUTPUT: | 1x RCA |
| HEADPHONE OUTPUT: | 10 V RMS |
| HEADPHONE RANGE: | 20 — 600Ω |
| INPUT VOLTAGE: | 115V OR 230V AC |
| DIMENSIONS: | 470 x 495 x 155mm (WXDXH) |
| NET WEIGHT: | 22.9KG (50Lb) |
